Equipment Installation
Safety Manual 3
–5
6. Fully ream all tubing ends. Blow out the line for 10 to 15 seconds
with clean, dry nitrogen or air prior to making the connection.
7. Connect the sample supply tube to the SCS using the 1/4” stainless
steel compression-type fitting provided.
8. Tighten all new fittings 1-1/4 turns with a wrench from finger tight.
For connections with previously swaged ferrules, thread the nut to
the previously pulled up position, then tighten slightly with a wrench.
Secure tubing to appropriate structural supports as required.
9. Check all connections for gas leaks. SpectraSensors recommends
using a liquid leak detector.
Ventilation Requirements
There are no special requirements for ventilation of the analyzer. Refer to
“Potential Risks Affecting Personnel” on page 2-5 for information related
to mitigating risks associated with process gases, etc.
Do not exceed 10 PSIG (0.7 barg) in sample cell. Damage to cell
may result.
