Endress+Hauser SpectraSensors SS2100 Safety Manual

SS2100 Analyzer
5–2 4900002253 rev. C 9-30-20
Topreventelectrostaticdischarge
1. Use a damp cloth to clean the displays to avoid static electricity
discharge.
Replacement Parts
All parts required for operation of the SS2100 analyzer must be supplied by
SpectraSensors or an authorized agent. Refer to Service Contact for contact
information to determine specific parts listing for the purchased model.
Fuse Ratings and Characteristics
If you need to replace a fuse, use only the same type and rating
of fuse as the original. Refer also to specifications listed in
Table 5-1 below.
Select the replacement solenoid fuse (F2) based on the number
of solenoids installed on the analyzer.
Table 5-1 Fuse specifications
Drawing Reference Voltage Description Rating
Figure
5–1
F1
120
VAC
1 Solenoid, Miniature Fuse, 5
x 20 mm, Time Delay
250 VAC
0.125 A
2 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.25 A
3 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.4 A
F2
120
VAC
Miniature Fuse, 5 x 20 mm,
Time Delay
250 VAC
0.8 A
F1
240
VAC
1 Solenoid, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
0.63 A
2 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
1.25 A
3 Solenoids, Miniature Fuse,
5 x 20 mm, Time Delay
250 VAC
2.0 A
F2 240
VAC
Miniature Fuse, 5 x 20 mm,
Time Delay
250 VAC
1.6 A
