Chapter 3 Installation
ThischapterdescribeshowtoinstalltheENH200.ItalsodescribestheENH200LEDs.

Onlyexperiencedinstallationprofessionalswhoarefamiliarwithlocalbuildingandsafety
codesand,whereverapplicable,arelicensedbytheappropriategovernmentregulatoryauthorities
shouldinstalltheENH200.

3.1Pre‐installationGuidelines

Selecttheoptimallocationsfortheequipmentusingthefollowingguidelines:
- TheENH200shouldbemountedona1"‐4"pole.Itslocationshouldenableeasyaccesstothe
unitanditsconnectorsforinstallationandtesting.
- Thehighertheplacementoftheantenna,thebettertheachievablelinkquality.
- Theantennashouldbeinstalledtoprovideadirect,ornearlineofsightwiththeBaseStation
antenna.TheantennashouldbealignedtofacethegeneraldirectionoftheBaseStation.

3.2InstallingtheENH200
ToinstalltheENH200,usethefollowingproceduretomountthedeviceonapoleandrefertothe
figurebelow.
1. ThebottomoftheENH200isamovablecover.Grabthecoverandpullitbackhardto
removethecover.
2. InsertastandardEthernetcableintotheRJ‐45portlabeledMAINLAN.
3. SlidethecoverbacktosealthebottomoftheENH200.
4. RemovethepowercordandPoEinjectorfromtheboxandplugthepowercordintothe
DCportofthePoEinjector.
 OnlyusethepoweradaptersuppliedwiththeENH200.Usingadifferentpoweradapter
mightdamagetheENH200.
5. PlugtheothersideoftheEthernetcableinstep3intothePoEportofthePoEinjector.
Whenyoufinishstep5,theinstallationwillresemblethefollowingpicture.
