13.4 WDS Bridge Mode
In WDS Bridge Mode, the ENH200 can wirelessly connect different LANs by configuring the
MAC address and security settings of each ENH200 device. Use this mode when two wired
LANs located a small distance apart want to communicate with each other. The best solution
is to use the ENH200 to wirelessly connect two wired LANs, as shown in the following figure.
WDS Bridge Mode can establish 16 WDS links, creating a star-like network.
WDS Bridge Mode is unlike Access Point. Access Points linked by WDS are using the same
frequency channel, more Access Points connected together may lower throughput. Please be
aware to avoid loop in your wireless connection, otherwise enable Spanning Tree Function.
