100BASE-TX Twisted Pair Network

2-2 Network Requirements

100BASE-TX Twisted Pair Network

Whenconnectinga100BASE‐TXsegmenttooneofthefixedRJ45ports(oddnumbered

ports1‐15),useCategory5UTPcabling.The

deviceattheotherendofthetwistedpair

segmentmustmeetIEEE802.3‐2002100BASE‐TXFastEthernetnetworkrequirements for

the

SecureStackA2tooperateat100Mbps.

1000BASE-T Twisted Pair Gigabit Ethernet Network

TheoptionalMGBIC‐02supports1000BASE‐TcompliantRJ45copperconnections.When

connectinga1000BASE‐Tsegment,useCategory5UTPcabling.Thedeviceattheother

endofthetwistedpairsegmentmustmeetIEEE802.3‐20021000BASE‐TGigabitEthernet

networkrequirementsforthedevicestoop erateat1000

Mbps.

WhentheA2isinstand alonemode(notstacked),thetwostackports17and18maybe

user‐configuredtoserveasastandardswitchportsallowingGigabituplinktothe

network.

100BASE-FX Multimode Fiber-Optic Network

TheA2H254‐16provides8portsthatsupport100Mbpsmultimodefiber‐optic

connectivityusingthefixedfront‐panelMT‐RJports(evennumberedports2‐16).The

MT‐RJfixedfront‐panelportssupport100BASE‐FXfiber‐opticcabling.Thedeviceatthe

otherendofthefiber‐opticsegment

mustmeet100BASE‐FXFastEthernetnetwork

requirementsforthedevicestooperateat100Mbps.IEEE802.3u100BASE‐FX

characteristicsforMultimodeFiberisasegmentlengthof412meters(switchedport)in

halfduplex,2kilometers(switchedport)infullduplex.Thisdistancewillbeconsiderably

shorterfrom

arepeaterport.Makesuretocheckyournetworkdiameterspecifications.

RefertotheCablingGuidefordetails.

Note: When using the fixed RJ45 ports on the SecureStack A2 for 100 Mbps operation

use Category 5 UTP cabling with an impedance between 85 and 111 ohms for 100 Mbps

operation.

Enterasys SecureStack A2 A2H254-16 User Manual
