Connecting to Console Port for Local Management
SecureStack A2 Installation Guide 3-21
Whentheseparametersareset,theStartupscreenwilldisplay.Proceedto“Connectingto
theNetwork”onpage3‐23.
Figure 3-13 Connecting a VT Series Terminal
Connecting to a Modem
ToconnectamodemtoanEnterasysNetworksswitchmodemport(Fi gure3‐14),usea
UTPcableterminatedwithaDB9femaleconnectorandaDB25maleconnector,and
proceedasfollows:
Parameter Setting
Mode 7 Bit Control
Transmit Transmit=9600
Bits Parity 8 Bits, No Parity
Stop Bit 1 Stop Bit
1. ConnecttheDB9femaleconnectoratoneendofthecabletotheConsoleportDB9
connectorontheEnterasysswitch.(IfthereisaswitchdesignatedastheManager,
connecttoitsConsoleport.)
2. PlugtheDB25maleconnectoratthe otherendofthecableintothemodem
communications
port.
3. Turnonthe modemand make suretheremotemodemisON.
4. WithyourPCconnectedtotheremotemodem,configureyourVTemulationpackage
withthefollowingparameters:
1 DB9 female connector 4 DB25 female connector
2 Serial interface cable 5 PC with VT emulation application
3 DB9 male Console port connector
