33
IP2288EN
EN
Display Description
RL - Loading of last configuration set
→
→
2”
The control panel automatically saves the last configuration set, and keeps it memorised in
the storage module.
In the event of a fault or the replacement of the control panel, the last configuration of the auto-
mation can be restored by inserting the storage module and loading the last configuration set.
15.6.1 Additional SF level parameters that can be configured
(available with → enabled)
Display Description
SP - Setting the password
[esempio]
→
2”
→→ →→
NB: this can only be selected when the password is not set.
Setting the password prevents unauthorised personnel from accessing selections and
adjustments.
You can delete the set password by selecting the sequence JR1=ON, JR1=OFF, JR1=ON.
IP - Inserting the password
[esempio]
→
2”
→→ →→
NB: this can only be selected when the password is set.
When the password is not inserted, you can access the display mode regardless of the
selection made with JR1.
When the password is inserted, you can access in maintenance mode.
EU - Deletion of user configurations and last configuration set in the storage module
→
→→
2” 2”
AL - Alarm counter
Used to view, in sequence, the counters of alarms that have been triggered at least once
(alarm code + number of times triggered).
With
and , you can scroll through all the counters and see all the alarms
recorded.
AH - Alarm log
Used to view, in sequence, alarms that have been triggered
(maximum 20).
With
and , you can scroll through the entire alarm log.
The display shows the alarm number and code, alternated.
The highest number corresponds to the most recent alarm and the lowest number (0)
corresponds to the oldest alarm.
SF - Special Functions
SF
(example)
(example)
