15.9.1 Additional AP level parameters that can be configured
(available with → enabled)
Display Description
Selections
available
20 - Partial opening command of terminal 1-20
P3 - Partial opening command
1-2 - Enabling of automatic closure
1-9 - Stop input
LU - Setting the courtesy light switch-on time (s)
To enable the parameter, set the selection
→ as "courtesy
light".
It is set with different intervals of sensitivity.
NO - Disabled
- from 01” to 59” with intervals of 1 second
- from 1’ to 2’ with intervals of 10 seconds
- from 2’ to 3’ with intervals of 1 minute
ON - Permanently enabled (switched off via remote control)
NB: the courtesy light switches on at the start of each operation.
LG - Switch-on time for independently commanded courtesy light
[s]
To enable the parameter, set the selection
→ as "courtesy
light".
It is set with different intervals of sensitivity.
NO - Disabled
- from 01” to 59” with intervals of 1 second
- from 1’ to 2’ with intervals of 10 seconds
- from 2’ to 3’ with intervals of 1 minute
ON - Switched on and off with remote control
NB: the switching on of the light does not depend on the start of an
operation, but can be commanded separately using the special remote
control key.
PT - Fixed partial opening
ON - Enabled
OF - Disabled
If ON, a partial opening command given on the partial opening posi-
tion is ignored.
With contact 1-20 closed (for example with the timer or manual se-
lector), the gate will partially open. If it is then fully opened (command
1-3) and reclosed (even with automatic closure), it will stop at the
partial opening position.
DE - Disengagement setting if an edge is triggered [cm]
Regulates the disengagement distance when an edge (active or pas-
sive) is triggered during opening or closure.
00 - Deactivated
20 - Maximum
10
DO - Setting of disengagement on stop during opening [mm]
Regulates the distance of the disengagement on the mechanical
opening stop.
00 - Disabled
15 - Maximum
NB: not active if
→
07
AP
