9.2.2 Configure Ethernet Interface #1
SLAAC is disabled by default in an nShield Connect, but can be selectively enabled for each Ethernet
interface either using the nShield Connect front panel or by setting the appropriate configuration item
and pushing an nShield Connect configuration file.
9.2.2 Configure Ethernet Interface #1
To set up Ethernet interface #1 (default):
9.2.2.1 Enable/disable IPv4
To enable/disable IPv4:
1. From the front panel menu, select System > System configuration > Network config > Set up
interface #1 > Configure #1 IPv4 > IPv4 enable/disable.
The following screen displays:
Network configuration
IPv4 enable/disable:
ENABLE
CANCEL FINISH
2. Set the ENABLE/DISABLE field to the required option.
3. To accept, press the right-hand navigation button.
9.2.2.2 Set up IPv4 static address
To set up IPv4 static address:
1. From the front panel menu, select System > System configuration > Network config > Set up
interface #1 > Configure #1 IPv4 > Static IPv4 address.
The following screen displays:
Network configuration
Enter IPv4 address
for interface #1:
xxx.xxx.xxx.xxx
Enter netmask:
xxx.xxx.xxx.xxx
CANCEL NEXT
2. Set each field of the IP address and netmask for the interface (press the Select button to move to
the next field).
3. Once all fields have been set, press the right-hand navigation button to continue.
4. To accept the changes, press the right-hand navigation button and then CONTINUE to go back
to the Static IPv4 address menu.
nShield® Connect - Installation Guide
Page 46
