9.2.2.5 Set the link speed for Interface #1
5. You are asked whether you wish to accept the new interface. To accept, press the right-hand
navigation button.
6. From the front panel, select System > System configuration > Network config > Set up
interface #1 > Configure #1 IPv6 > Static IPv6 address > Static IPv6 Enab/Dis.
The following screen displays:
Network configuration
Do you want to enable
a static address? No
CANCEL FINISH
7. Select Yes and press the right-hand navigation button.
8. A screen will be displayed Static IPv6 address setup complete, select Continue.
9.2.2.5 Set the link speed for Interface #1
To set up the link speed for interface #1:
1. From the front panel menu, select System > System configuration > Network config > Set up
interface #1 > Set link speed for #1.
2. The following screen displays:
Network configuration
Select desired link
speed:
auto / 1Gb
CANCEL NEXT
You can choose from auto / 1Gb, 10BaseT, 10BaseT-FDX, 100BaseTX, or 100BaseTX-FDX.
We recommend that you configure your network speed for automatic negotiation, using
the auto / 1Gb or auto option. You will asked to confirm the changes if auto / 1Gb is
not selected.
On the nShield Connect, selecting auto / 1Gb is the only means of achieving 1Gb link
speed.
3. Press the right-hand navigation button and you will be returned to the Set up interface #1
screen and you can then continue with the configuration.
9.2.3 Configure Ethernet Interface #2
To set up the Ethernet interface #2, if required:
nShield® Connect - Installation Guide
Page 48
