Entrust Sigma DS3 Installation And Administrator's Guide

6 Printer Installation
Multi-Hopper Printer
Operating Environment
Use the following guidelines when operating the printer:
Operating temperature 60°–95° F (15°–35° C)
Operating humidity 20–80%, non-condensing
19.0 in
482 mm
6.1 in
155 mm
5.6 in
142.9 mm
4.2 in
108 mm
28.6 in
729 mm
9.0 in
229 mm
7.1 in
181 mm
11.2 in
284 mm

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
