Sigma DS1, DS2, and DS3 Card Printers Installation and Administrator’s Guide 53
Cards
For best results, use high-quality cards that meet the following specifications and
recommendations.
Card Size
Use ISO ID-1 cards (also called CR80 cards). The cards have the following dimensions:
Actual card thickness can vary by up to ten percent from the sizes listed. The card bow must be
less than the thickness of the card.
Card Material
Use cards with a glossy PVC surface, either 100% PVC cards or composite cards with a PVC
surface. Cards can have a magnetic stripe on one side of the card, and a smart card chip on the
front side.
Pre-Punched Cards
For best results, punch cards after printing
them. The cards can have a punched area
within 1 inch (25 mm) of the left edge, as
the cards are loaded in the printer. If the
card has a magnetic stripe, the card cannot
be punched anywhere in the stripe.
Length 3.37 inches 85.60 mm
Width 2.125 inches 53.98 mm
Thickness
 Print only: 0.010 to 0.040 inches
 Magnetic stripe cards:
0.020 to 0.030 inches
 0.254 to 1.016 mm
 0.508 to 0.762 mm
0.56 in
(14.3 mm)
maximum
0.20 in
(5.5 mm)
maximum

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
