Sigma DS1, DS2, and DS3 Card Printers Installation and Administrator’s Guide 17
Connect the Printer to a Computer
You can connect the printer to a Windows-based PC using either a USB cable, or through a
network using an Ethernet cable (the Ethernet cable is not supplied with the system). Refer to
“Run the QuickInstaller” on page 19 and follow the instructions in the QuickInstaller to complete
the printer connection.
Connect Using a USB Cable
1. Connect one end of the USB cable to the USB port of the
printer.
2. Connect the other end to a USB port on the PC when
you are prompted by the QuickInstaller.
Connect Using a Network Cable
1. Connect one end of the Ethernet cable to the network
connection port on the printer.
2. Connect the other end to a network port.
3. Follow the instructions in the QuickInstaller to complete
the installation.
If you plan to use the XPS Card Printer Driver, do not connect the USB cable to the
computer until you are prompted during installation of the Driver.
Refer to the XPS Card Printer Driver User’s Guide to set up the Card Printer Driver to
work with the printer.
To
Computer

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
