Sigma DS1, DS2, and DS3 Card Printers Installation and Administrator’s Guide 27
4. Press E
NTER to view or change the prefix length.
The prefix length indicates the boundary between the
subnet to which the host is connected and the device ID in
the IPv6 manual address. Press the up or down arrow to
change the prefix length.
5. Press E
NTER to save your changes. Then, press the down
arrow to display Gateway Address on line 3.
6. Press E
NTER to enter the default gateway address.
a. Follow the procedure described in step 2 to enter the
gateway address.
b. When all three screens are correct, press E
NTER to save
the gateway address.
7. Press the down arrow until Exit displays on line 3.
8. Press E
NTER. Then, press the USER button to return the
printer to Ready.
Run a SSA Test Card
Use the printer’s front panel to print a SSA test card to configure the magnetic stripe start sentinel
alignment (SSA). Make sure that a magnetic stripe card is loaded in the input hopper or hopper 1
of the multi-hopper (the lower left hand hopper) before you begin.
The start sentinel for magnetic stripe encoding must be adjusted after installing the
multi-hopper to prevent magnetic stripe read/write errors. Perform the adjustment
by running a magnetic strip card using the SSA test.
Load Card in
Hopper 1

Entrust Sigma DS3 Specifications

General

Print Resolution	300 dpi
Card Capacity Input Hopper	100 cards
Card Capacity Output Hopper	25 cards
Power Supply	100-240 VAC, 50/60 Hz
Print Technology	Dye sublimation
Print Capabilities	Single or dual-sided
Card Thickness	0.010 inches to 0.040 inches
Supported Card Sizes	CR80 (85.6 mm x 54 mm)
Connectivity	USB and Ethernet
Operating System Support	Windows 7, 8, 10, Server 2008, 2012, 2016
Weight	5.49 kg (12.1 lbs)
Operating Temperature	15°C to 35°C (60°F to 95°F)
Operating Humidity	20% to 80% (non-condensing)
Print Speed	Up to 250 cards per hour (YMCKT)
