Sigma DS1, DS2, and DS3 Card Printers Installation and Administrator’s Guide 9
Secure the Printer (Optional)
You can secure the printer using one of the following:
An optional cable lock (refer to “Use the Optional Cable Lock”).
Bolt-down openings in the bottom of the printer (refer to “Use the Bolt-Down Openings”).
Use the Optional Cable Lock
The cable lock is a user-installed feature that does not require special tools to install. The package
contains a cable lock, a metal security plate, and instructions. The security plate is installed in the
printer and is designed to accommodate the T-bar of the cable lock.
1. Prepare the printer by installing the metal security plate:
a. Tip the printer on its right side.
b. Locate the security plate receptacle on the back left
side of the printer.
c. Insert the security plate into the receptacle with the
open end toward the printer.
d. Insert the T-bar of the cable lock through the printer
opening into the security plate.
2. Follow the instructions included with the cable lock to
complete the installation.
Use the Bolt-Down Openings
The printer includes bolt-down openings that you can use to secure it to a mounting surface.
You need the following supplies:
The bolt-down kit (part no. 529349-001) contains two M6 well nuts.
Two M6 (6 mm) screws, purchased separately.
The length of the screws you need depends on the thickness of the mounting surface. The
screw length is the surface thickness + 0.75 inch (20 mm).
Two M6 washers, purchased separately.
1/4-inch (7 mm) drill bit.
The cable lock is available with either a key or combination lock.
