Table 2.2 Lubricants
Code Type Specication Amount Position
A
Anti-wear hydraulic oil L-HM46 See Table 2.3
Hydraulic
System
B
Multi-purpose grease Polylub GA352P Appropriate amount
Sliding surface
(See Table 2.4)
C
Heavy duty gear oil 85W-90GL-5 4.5L (Align with oiling port) Drive Axle
D Brake uid
ZSM207DOT3
After the gas within the
system is completely
discharged, add to 2/3 of
the oil cup
Brakes
Table 2.3 Application Amount of
Hydraulic Oil 1-2
Mast Series
Lifting height
(mm)
Amount
(L)
Full Free
2-stage Mast
2000 30
2500 34
2700 34
3000 36
3300 36
3500 38
Wide-view
2-stage Mast
2000 30
2500 34
2700 34
3000 36
3300 36
3500 38
3600 38
4000 42
4300 42
4500 44
Table 2.3 Application Amount of
Hydraulic Oil 2-2
Mast Series
Lifting height
(mm)
Amount
(L)
3-stage Mast
4300 38
4500 40
4800 42
5000 44
5500 46
6000 45
3. TROUBLESHOOTING
