ep ICE301B - Cylinder Installation; Built-In Side Shifter; External Side Shifter; Rev. 09;2020

REV. 09/2020
MAST
8
98
If the piston rode or cylinder tube is damaged,
please replace the entire cylinder.
If the seals are aged or damaged, please
replace the complete set of seals.
CAUTION
Full Free Middle Cylinder
Reference Section 8.2.4.2.
8.3.4.3 Cylinder Installation
-
-
-
-
-
Install the cylinder according to the reverse
order of removal according to 8.3.4.1;
Add hydraulic oil of the same specifications
into the tank, see Section 2.2.3;
Pull out emergency stop switch and turn on
the key switch;
Repeat Lift - Lower cylinder to discharge the
air within the tubings and cylinder;
Check the hydraulic oil level and make sure
that the liquid is at standard level.
8.3.5 Built-in Side Shifter
8.3.6 External Side Shifter
Reference Section 8.1.5.
Reference Section 8.1.6.
