ep ICE301B - General Tightening Torques

REV. 09/2020
7
REV. 09/2020
INFORMATION & SPECIFICATIONS INFORMATION & SPECIFICATIONS
1 1
6
Table 1.4.1 Screws/Bolts Performance Levels
Performance Level Material Specication (mm)
5.8 grade Low carbon steel M6 ~ M48
8.8 grade
Quenched and tempered medium
carbon steel
M6 ~ M48
10.9 grade
Quenched and tempered medium
carbon alloy steel
M6 ~ M48
12.9 grade
Quenched and tempered medium
carbon alloy steel
M6 ~ M48
Table 1.4.2 Metric Screws/Bolts Tightening Torque Table (n•m)
Nominal Diameter
(mm)
Performance Level
5.8 8.8 10.9 12.9
Proof Stress (MPa)
380 600 830 970
M6 7~8 10~12 14~17 17~20
M8 16~18 25~30 34~41 41~48
M8×1 17~20 27~32 37~43 43~52
M10 31~36 49~59 68~81 81~96
M10×1 35~41 55~66 76~90 90~106
M12 55~64 86~103 119~141 141~167
M12×1.5 57~67 90~108 124~147 147~174
M14 87~103 137~164 189~224 224~265
M14×1.5 144~170 149~179 206~243 243~289
M16 136~160 214~256 295~350 350~414
M16×1.5 144~170 228~273 314~372 372~441
M18 186~219 294~353 406~481 481~570
M18×1.5 210~247 331~397 457~541 541~641
M20 264~312 417~500 576~683 683~808
M20×1.5 294~345 463~555 640~758 758~897
M22 360~431 568~680 786~941 918~1099
M22×1.5 395~473 624~747 803~1034 1009~1208
M24 457~547 722~864 998~1195 1167~1397
M24×2 497~595 785~940 1086~1300 1269~1520
M27 669~801 1056~1264 1461~1749 1707~2044
M27×2 723~865 1141~1366 1578~1890 1845~2208
M30 908~1087 1437~1717 1984~2375 2318~2775
M30×2 1005~1203 1587~1900 2196~2629 2566~3072
M36 1587~1900 2506~3000 3466~4150 4051~4850
M36×3 1680~2011 2653~3176 3670~4394 4289~5135
M42 2538~3039 4088~4798 5544~6637 6479~7757
M42×3 2731~3269 4312~5162 5965~7141 6921~8345
M48 3813~4564 6020~7207 8327~9969 9732~11651
M48×3 4152~4970 6556~7848 9069~10857 10598~12688
12.9
10.9
8.8
5.8
1.4 General Tightening Torques
Screws or bolts used on the truck are of 8.8
grade or higher performance level.
When you are conducting truck maintenance,
you can refer to Table 1.4.1 and Table 1.4.2 to
select the suitable screws or bolts for replace-
ment.
-
-
CAUTION
The performance levels of screws or bolts are
marked on the heads of the screws or bolts.
If you nd the screws or bolts used on certain
position are not marked with performance
level, please select spare parts with perform-
ance level of at least 8.8 grade or higher level
for replacement.
