Epec CAN Module Family
2024 CONTROL MODULE
23 / 34
07.10.2010
2024G08,G18 / MAN000185
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
3.11 AMPSEAL Connectors
Epec uses gold plated, locked and sealed AMPSEAL heavy duty connectors for all Epec CAN
Module Family products to ensure the endurance of extreme conditions.
• 8-pin AMPSEAL for power and system CAN connections
• 3 x 23-pin AMPSEAL for I/O
• All connectors are mechanically keyed to mate only with identical colors
AMPSEAL connectors Epec ordering code
AMP 23-pin grey plug (female) KX0007
AMP 23-pin black plug (female) KX0008
AMP 23-pin blue plug (female) KX0009
AMP 8-pin black plug (female) KX0187
3.12 AMPSEAL Cable Dimensions
Size
Insulation
diameter range
Strip length ±0,4
mm
AWG
0,5 20 1,7 5,1
0,8 18 to 5,1
1,4 16 2,7 5,1
Typical hand crimping tool e.g.:
AMP Procrimper 58529-1,
Epec ordering code TT0018
• All applied cables should be properly shielded, bundled and grounded
• See the General Mounting and Cabling Instructions for Epec Modules for more detailed
information about the cabling
