Epec CAN Module Family
2024 CONTROL MODULE
26 / 34
07.10.2010
2024G08,G18 / MAN000185
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
6 ENVIRONMENTAL CHARACTERS
Epec CAN module family is designed for extreme environments and the product family is
certified with normal automotive (e17) EMC standards and has shock and vibration endurance
up to 100 G.
• Operating temperature -40°C … +70°C
• Storage temperature -50°C … +85°C
6.1 Protection
• IP67 (classification according to IEC 60529)
• Module is equipped with Oil Rating 7 (according to test method AATCC 118-1997ASTM)
hydrophobic and oleophobic Gore HPM Membrane Vent
• Protection for plugs depends on cable processing
• All cables, connectors and tools must be of correct type and sufficiently high quality. Also the
environmental suitability of equipment should be checked (protection for moisture,
mechanical stability, power durability, coupling resistance, among other things)
• Additional module cover for wires and connectors is also available
6.2 EMC Tests
Epec 4G modules are certified according to following tests:
ISO/DIS 14982 (1998)
Agricultural and forestry machines-electromagnetic compatibility-test methods and acceptance
criteria
Electrostatic discharge (ESD) immunity test
8
Transient and surges in vehicular
environment immunity test
Note: The Mini module (2038) and the Mini
display (2029) need the Hub module (2021)
in order to have the full transient immunity.
Test method ISO 7637-2 (1990), pulse 5
• Performance criterion B
Pulse Pulse parameters
5
Us=+70V,
tr=10ms, td=600ms
Commission directive 72/245/EEC, as last amended by commission directive
2006/28/EC Requirements to be met by vehicles and electrical/electronic sub-assemblies
fitted to a vehicle
