Epec CAN Module Family
2024 CONTROL MODULE
24 / 34
07.10.2010
2024G08,G18 / MAN000185
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
4 POWER SUPPLY
• Nominal supply voltage 24 VDC
• Operating range 10…30 VDC
• No saving operations (program flashing or parameter storing) into permanent memory can
be done under 11,5 VDC.
• Undervoltage reset ≤ 9,5 VDC
4.1 Overvoltage Protection
• Max. 70 VDC (Stresses above this value may cause permanent damage to the module.)
• Module has a shutdown circuit which protects the module and loads against overvoltage.
The shutdown circuit cuts off the power feed for the logic and loads in case of overvoltage.
The shutdown circuit is activated when voltage reaches circa 32 V. Power feed is restored
when supply voltage drops to 30 V.
4.2 Power Consumption
• Approx. 1,8 W (+24 VDC, no external load)
• Supply Voltage (V
SUPPLY
) maximum continuous current 13 A (with full external load)
• GND current sum max 13 A
4.3 Power Supply Pins
Designation
Connector /
pin number
Potential
Supply voltage X4.4
X4.5
+24 VDC (+10…30 VDC)
Ground (for supply voltage) X4.1
X4.3
GND
Optional back-up supply * voltage
for CPU
X2.11 +24 VDC
Auxiliary supply for external devices X1.13 V
SUPPLY
/ max 3 A
Internally regulated and monitored
auxiliary supply for external devices
X3.1
X3.9
+12 VDC / max 200 mA
(max total for all pins together)
Internally regulated and monitored
auxiliary supply for external devices
X3.2
X3.10
+5 VDC / max 250 mA
(max total for all pins together)
Ground X1.9
X1.10
X1.11
X2.13
X2.14
X2.15
X3.3
X3.4
X3.11
X3.12
GND
(3 A/pin)
* This pin does not provide power supply for current sourcing outputs. Please consult the
manufacturer before using this pin as a module voltage supply.
