3 INPUT / OUTPUT SPECIFICATIONS
I/O module contains inputs and outputs or, in other words, I/O pins of many different types.
There are, for example, outputs which source current and outputs which sink current.
Furthermore, there are I/O pins which can be used as inputs or as outputs at the control of the
application programmer.
3.1 Configurable I/Os
Max
Amount
DI AI PI DO PWM
Digital
Input
Analog
Input
Current
Measuring
Feedback
Pulse
Input
Digital
Output
(sourcing)
Digital
Output
(sinking)
Pulse Width
Modulation
Output
4 x
4 x
24 x x x
8 x x
4 x x
8 x x
52 48 12 8 28 24
The usage of each I/O pin is determined by the application.

Epec 2024 Specifications

General

Brand	Epec
Model	2024
Category	Control Unit
Language	English
