Epec CAN Module Family
2024 CONTROL MODULE
27 / 34
07.10.2010
2024G08,G18 / MAN000185
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
Radiated disturbance emission test
Test method 2005/83/EC, ANNEXES VII and
VIII
Frequency
(MHz)
Limit value (dBμV/m)
30 – 1000
62/52/63
(Broadband QP)
30 – 1000
52/42/53
(Narrowband AVE)
Conducted disturbances emission test
Test method 2005/83/EC, ANNEX X
Port Limit level (V)
24 V DC input
+150
-450
Immunity to transient disturbances
conducted along supply lines test
Note: The Mini module (2038) and the Mini
display (2029) need the Hub module (2021)
in order to have the full transient immunity.
Test method 2005/83/EC, ANNEX X
• Performance criterion:
Pulse Criterion
1 C
2a B
2b C
3a A
3b A
4 C
Pulse Pulse parameters
1
3/2000
s, -600 V, 1000 pulses
2a
1/50
s, +100 V, 1000 pulses
2b 20 V, 220 ms, 2 pulses
3a 5/100 ns, -200V, 60minutes
3b 5/100 ns, +150 V, 60minutes
4 100 ms -20,5(8,0) V, 20s -
16,5(12,0) V, 2 pulses
