Epec 2024 User Manual

Epec CAN Module Family
2024 CONTROL MODULE
28 / 34
07.10.2010
2024G08,G18 / MAN000185
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
Radiated radio-frequency electromagnetic
field immunity test
•
Test method 2005/83/EC, ANNEX IX
• Performance criterion: No degradation of
‘Immunity-related functions’
Specification
Frequency
Range
(MHz)
Test
level
Modulation
AM80% 1 kHz
Sweep step 1%,
time/step 3s
20-800 30 V/m
PM
577/4600μs
800-2000 30 V/m
EN 61000-6-3 (2001)
Electromagnetic compatibility-generic emission standard
part6-3: residential, commercial and light industry
Radiated disturbance emission test
Note: The Color display (2040) needs extra
facilities in order to have the limit B
covered.
•
Test method EN 55022 (1994)
Limit
Frequency
(MHz)
Limit value
(dBμV/m)
A 30 – 1000 40/47 (QP)
B 30 – 1000 30/37 (QP)
Conducted disturbance at main ports
emission test
•
Test method EN 55022 (1994)
Frequency
(MHz)
Limit value (dBμV)
0,15 - 30 66/56/60 (QP)
0,15 – 30 56/46/50 (AVE)
EN 61000-6-2 (2005)
Electromagnetic compatibility-generic immunity standard
part6-2: industrial environment
