Epec CAN Module Family
2024 CONTROL MODULE
29 / 34
07.10.2010
2024G08,G18 / MAN000185
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
Conducted radio-frequency common mode
immunity test
Test method EN 61000-4-6 (1996)
• Performance criterion A
Specification Port Test level
Frequency range
0,150-80 MHz
Modulation
AM80% 1 kHz
Sweep step 1%,
time/step 3s
DC input
port
10 Vemf
Signal
ports
10 Vemf
Radiated radio-frequency electromagnetic
field immunity test
Test method EN 61000-4-3
• Performance criterion A
Specification
Range
(MHz)
Test
level
Frequency range
80-2700 MHz
Modulation
AM80% 1 kHz
Sweep step 1%,
time/step 3s
80-1000 20 V/m
1000-2700 3 V/m
Electrical fast transient (EFT/B) immunity
test
Test method EN 61000-4-4 (1995)
• Performance criterion B
Test pulse Port Test level
5(Tr)/50(Th) ns,
repetition
frequency
5 kHz, duration
1 minute
DC input
port
± 2,0 kVp
Signal
ports
± 2,0 kVp
CFR 47 Part 15, Subpart B, Class A and B
Code of federal requlations (cfr) title 47 telecommunication, part15 radio frequency devices,
subpart b unintentional radiators
Class a intended for use in industrial/commercial environments
Class b intended for use in residential/small office environments
Radiated emissions
Note: The Color display (2040) needs extra
facilities in order to have the class B
covered.
Test method ANSI C63.4 and EN55022
Class
Frequency
(MHz)
Limit value
(dBμV)
A 30 – 1000 40/47 (QP)
B 30 – 1000 30/37 (QP)
