 MMS6110Directionforuse
 Configuration  Page10



Forthedualchannelmodewithtwocharacteristicalvalues,bothchannelshavetobeconfig-
uredseparately.Ifanoperatingmodehasbeenselectedwithonlyonecharacteristicalvari-
ablecalculatedfromtheresultsofbothchannels,thereisonlyonepropertypageforboth
channels.
Withaccessauthorization"OPERATION"thechannelsmayonlybeactivated/deactivated,
withauthorization"SERVICE"allparameterscanbeedited.
ParameterswitchChannel
Byclickingparameterswitch"channel"withthemouse,therelevantchannelcanbeacti-
vated/deactivated.Ifthechannelisdeactivated,calculationofcharacteristicalvalues,limit
watchingandchannelsupervisionareswitchedoff.
EntryfieldsKKSandDescription
Thesefieldscanbefilledinaccordingtotheuser'srequirements.Bothfieldsrequireinputsof
parameters.Aslongasnoentriesweremadeinthefields,thefieldsareindicatedred.
PreferablytheKKSnumberisenteredhereaccordingtothepowerplantidentificationsystem
underwhichsensorormeasuringchainaredocumented.Thisdesignationwillbestoredin
themoduleandisthenbeusedtoidentifythismodule.
Foroperatingmodeswheretheresultsofbothchannelsarecombined(Smax,Sppmax)six
inputfieldsareavailable.TheupperfieldsareforKKSnumberanddesignationoftheout-put
channelofthecombinedcharacteristicalvalueandtwofurtherfieldsforeachofthemeasur-
ingchannels.

