41
Battery Configuration Process LCD Displaying
Step5: Press “ ” button to save all the settings
and return to the main page.
Lithium batteries, lead acid batteries and lithium iron phosphate batteries are
recommended to use with NAVY Evo. Other types of battery may fail to make
NAVY Evo work properly.
When you use the below batteries, please set battery type and rated voltage val-
ue based on the parameters in the following table.
Battery type Nominal Voltage options
LI 43.2V 44.4V 45.6V 46.8V 48.1V 49.4V 50.4V 51.8V 53.2V
Pb 44.0V 46.0V 48.0V 50.0V 52.0V 54.0V
LFE 44.8V 48.0V 51.2V
Update the battery conguration is necessary if a different type of battery has
been applied.
When using non-ePropulsion batteries, before starting the outboard, users
should congure the batteries via the Evo Control System for the rst time use,
otherwise the batteries may not work properly.
