Connectors
No. Name Description
1
Wire saddle Pass the USB cable through this saddle to prevent disconnection of the
cable.
2 AC inlet Connect the power cable.
3 LAN port Connect a LAN cable.
4 USB B port Connect a USB Type B cable.
5
USB A port (for connecting an optional
device)
Connect the optional Wireless LAN Unit.
CW-C4000 Series User’s Guide
Before use
22
