Adjusting the Shutters
Inside the front cover, there are shutters for adjusting paper suction for during printing.
e shutters need to be correctly opened/closed to match the paper width used. To open/close them, move them
with a
nger.
Furthermore, the paper width can be checked on the label at the top of the main unit.
!
Caution
If the shutters are not correctly opened/closed, paper may be jammed or smudged with ink.
Paper width / Backing paper width Shutter state
25.4 to 43.8 mm
Close all the shutters.
43.9 to 58.4 mm Open the innermost shutters.
58.5 to 73.0 mm Open the inner four shutters.
CW-C4000 Series User’s Guide
Basic Operation
51
