Epson EB-410W User Manual

12
Changing the Projected Image (Source Search)
The projector automatically detects signals being input from connected
equipment, and the image being input from the equipment is projected.
You can project the target image quickly because it skips input ports
where no image is being input.
When your video equipment is connected, start playback before beginning
this operation.
When two or more pieces of equipment are connected, press the
[Source Search] button until the target image is projected.
Procedure
Computer1 Video
The input port where no image
signal is being input is skipped.
S-VideoComputer2
Using the remote control
Using the control panel
q
The following screen showing the status of image signals is
displayed when only the image that the projector is
currently displaying is available, or when no image signal
can be found. You can select the input port where the
connected equipment you want to use is projecting. If no
operation is performed after about 10 seconds, the screen
closes.

Epson EB-410W Specifications

General

Matrix size	0.56 \
Number of colors	16.78 million colors
Projection distance	0.62/7.83 m
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-15 - 15 °
Throw ratio	0.48 - 0.65:1
Focal length range	6.48 mm
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
RMS rated power	10 W
Number of built-in speakers	1
Dimensions (WxDxH)	258 x 327 x 95 mm
Power requirements	100-240 V AC ± 10%, 50/60 Hz
Connectivity technology	Wired
Serial interface type	RS-232
Noise level	28 dB
Power consumption (standby)	5.5 W
Power consumption (typical)	236 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	3600 g
