Epson EB-410W User Manual

51
Replacing Consumables
This section explains how to replace the remote control batteries, the
lamp, and the air filter.
Replacing the Remote Control Batteries
If delays in the responsiveness of the remote control occur or if it does not
operate after it has been used for some time, it probably means that the
batteries are becoming flat. When this happens, replace them with new
batteries. Have two spare AA-size alkaline or manganese dry batteries
ready to use. You can only use AA-size alkaline or manganese dry
batteries.
A
Remove the battery cover.
While pushing the battery cover catch, lift the cover up.
B
Replace the old batteries with new batteries.
Caution
Check the positions of the (+) and (-) marks inside the battery
holder to ensure the batteries are inserted the correct way.
C
Replace the battery cover.
Press the battery cover until it clicks into place.
Attention
Make sure you read the Safety Instructions/Support and Service
Guide before handling the batteries. sSafety Instructions
Procedure
Catch

Epson EB-410W Specifications

General

Matrix size	0.56 \
Number of colors	16.78 million colors
Projection distance	0.62/7.83 m
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-15 - 15 °
Throw ratio	0.48 - 0.65:1
Focal length range	6.48 mm
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
RMS rated power	10 W
Number of built-in speakers	1
Dimensions (WxDxH)	258 x 327 x 95 mm
Power requirements	100-240 V AC ± 10%, 50/60 Hz
Connectivity technology	Wired
Serial interface type	RS-232
Noise level	28 dB
Power consumption (standby)	5.5 W
Power consumption (typical)	236 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	3600 g
