Epson EB-410W User Manual

Replacing Consumables
56
Replacing the Air Filter
f Air filter replacement period
It is time to replace the air filter when:
• The air filter is ripped.
• The message is displayed even though the air filter has been
cleaned.
f How to replace the air filter
The air filter can be replaced even when the projector is suspended from a
ceiling.
A
After you turn off the projector's power and the
confirmation buzzer beeps twice, disconnect the
power cable.
B
Remove the air filter.
Put your finger into the recess of the air filter and slide it forward to
remove it.
C
Install the new air filter.
Slide the air filter in from the outside and push until it clicks into
place.
Procedure
q
Dispose of used air filters properly in accordance with your
local regulations. Do not dispose of it with normal waste.
Material quality of the frame section: Polycarbonate, ABS
resin
Material quality of the filter section: Polyurethane form

Epson EB-410W Specifications

General

Matrix size	0.56 \
Number of colors	16.78 million colors
Projection distance	0.62/7.83 m
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-15 - 15 °
Throw ratio	0.48 - 0.65:1
Focal length range	6.48 mm
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
RMS rated power	10 W
Number of built-in speakers	1
Dimensions (WxDxH)	258 x 327 x 95 mm
Power requirements	100-240 V AC ± 10%, 50/60 Hz
Connectivity technology	Wired
Serial interface type	RS-232
Noise level	28 dB
Power consumption (standby)	5.5 W
Power consumption (typical)	236 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	3600 g
