61
Connecting to External Equipment
Connecting to an External Monitor
Computer images being input to the Computer1 input port can be
displayed on an external monitor and the screen at the same time when
connected to the projector. This means that you can check projected
images on an external monitor when giving presentations even if you
cannot see the screen.
Connect to an external monitor using the cable supplied with the monitor.
Connecting to External Speakers
You can connect speakers with built-in amplifiers to the projector's Audio
Out port to enjoy a fuller quality of sound.
Connect with a commercially available audio cable (pin plug W 3.5 mm
stereo mini plug and so on). Use an audio cable compatible with the
connector on the external speakers.
q
• Component video signals and images connected to the
Computer2 port, Video port, and S-Video port cannot be
output to an external monitor.
• The setting gauge for Keystone, the configuration and
help screen, and so on are not output to an external
monitor.
Cable supplied
with monitor
To Monitor Out port
Monitor port
q
When an audio cable plug is inserted in the Audio Out port,
the audio changes to the external destination, and audio is
no longer emitted from the projector's built-in speaker.
To external
speakers
To Audio Out port
Audio cable
(commercially available)
To Next Page
