Epson EB-410W User Manual

58
Saving a User's Logo
You can save the image that is currently being projected as a user's
logo.
A
Project the image you want to use as the user's
logo, and then press the [Menu] button.
B
In the configuration menu, select "Extended"-
"User's Logo".
s "Using the Configuration Menu" p.25
Check the buttons you can use and the operations they perform in
the guide under the menu.
C
When "Choose this image as the User's Logo?" is
displayed, select "Yes".
q
When a user's logo is saved, the previous user's logo is
erased.
Procedure
Using the remote control Using the control panel
q
• If "User's Logo Protect" from "Password Protect" is set
to "On", a message is displayed and the user's logo
cannot be changed. You can make changes after setting
"User's Logo Protect" to "Off".
s p.20
• If "User's Logo" is selected when Keystone, E-Zoom,
Aspect, or Progressive are being performed, the function
currently being performed is cancelled.
q
When you press the [Enter] button on the remote control or
the control panel, the screen size may change as it changes
to the resolution of the image signal.

Epson EB-410W Specifications

General

Matrix size	0.56 \
Number of colors	16.78 million colors
Projection distance	0.62/7.83 m
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-15 - 15 °
Throw ratio	0.48 - 0.65:1
Focal length range	6.48 mm
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
RMS rated power	10 W
Number of built-in speakers	1
Dimensions (WxDxH)	258 x 327 x 95 mm
Power requirements	100-240 V AC ± 10%, 50/60 Hz
Connectivity technology	Wired
Serial interface type	RS-232
Noise level	28 dB
Power consumption (standby)	5.5 W
Power consumption (typical)	236 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	3600 g
