Supported Monitor Displays (EB-825H/824H/85H/
84H/84L)
Computer signals (analog RGB)
Signal Refresh Rate (Hz) Resolution (Dots)
VGA 60/72/75/85 640x480
SVGA 56/60/72/75/85 800x600
XGA 60/70/75/85 1024x768
WXGA 60 1280x768
60 1360x768
60/75/85 1280x800
WXGA+ 60/75/85 1440x900
SXGA 70/75/85 1152x864
60/75/85 1280x1024
60/75/85 1280x960
SXGA+ 60/75 1400x1050
UXGA 60 1600x1200
MAC13” 67 640x480
MAC16” 75 832x624
MAC19” 75 1024x768
59 1024x768
MAC21” 75 1152x870
Even when signals other than those mentioned above are input, it is likely that the
image can be projected. However, not all functions may be supported.
Component Video
Signal Refresh Rate (Hz) Resolution (Dots)
SDTV (480i) 60 720x480
SDTV (576i) 50 720x576
SDTV (480p) 60 720x480
SDTV (576p) 50 720x576
HDTV (720p) 50/60 1280x720
HDTV (1080i) 50/60 1920x1080
Composite Video/S-Video
Signal Refresh Rate (Hz) Resolution (Dots)
TV (NTSC) 60 720x480
TV (PAL,SECAM) 50/60 720x576
Supported Monitor Displays
107
