F
Edge guide Feeds the paper straight into the printer. Slide to the edges of the
paper.
G
Paper guide extension Slide out to load paper larger than A4 size.
A
Document cover Blocks external light while scanning.
B
Scanner glass Place the originals. You can place originals that are not fed from the
ADF such as envelopes or thick books.
C
Control panel Allows you to make settings and perform operations on the printer.
Also displays the printer’s status.
D
Paper cassette cover Open to load paper in the paper cassette.
Inside
A
Scanner unit Scans placed originals. Open to rell the ink tank or to remove
jammed paper. This unit should usually be kept closed.
B
Print head Ink is ejected from the print head nozzles underneath.
Part Names and Functions
>
Inside
18
