3-7
EMP-9000/8000
SEIKO EPSON Revision:A
3.2.3. Lamp Inner Housing
1. Loosen three screws fixing the Lamp Inner Housing .
2. Pull out the Lamp Inner Housing while holding the lever.
Figure3-4
Caution:
Pay attention to handling because the Lamp might be superheating Immediately after lamp is
used.
When installing the Lamp Inner Housing, take care not to touch the lamp’s reflector with a
hand (to prevent the reflector flom being contaminated).
3.2.4. Air Filter
1. Slide Fan cover under the main frame to direction of the arrow.
Figure3-5
To Next Page
