Epson Expression 1680 User Manual

90
Network Scanning
6. When you see the screen on the right, enter
the IP address or host name of the scanner
server in the Network Scanner Address box.
(You can only use a host name if you have a
DNS server on your network.)
7. Click
Test
to test the connection. You see a
message that the scanner is available in the
Scanner Status section of the window. Click
OK
to save your settings.
8. Follow the instructions on page 45 if you
want to install ScanSoft TextBridge Pro,
Adobe Photoshop LE, LaserSoft SilverFast,
or MonacoEZcolor.
9. When you’re done installing software,
restart your computer.
If you need to connect to a different network scanner or change the
timeout setting, you can open the EPSON TWAIN Pro Network window
anytime by selecting Control Panels from the Apple menu, then selecting
EPSON TWAIN Pro Net. You can enter up to five IP addresses or host
names in the Network Scanner Address box.
1680.book Page 90 Thursday, March 1, 2001 4:28 PM

Epson Expression 1680 Specifications

Scanning Specifications

optical resolution	1600 x 3200 dpi
maximum resolution	13, 600 x 18, 720 dpi with interpolation
effective pixels	13, 600 x 18, 720 pixels (1600 dpi)
color depth	48 bits per pixel internal/external
grayscale depth	16 bits per pixel internal/external
scanning speed (color, 1600 dpi, draft mode)	9.2 msec/line (approx.)
scanning speed (grayscale/monochrome, 1600 dpi, draft mode)	3.1 msec/line (approx.)

Operating Environment

temperature operating range	41ºF to 95ºF (5ºC to 35ºC)
humidity operating range	10% to 80% (no condensation)
humidity storage range	10% to 85% (no condensation)

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption (operating without optional unit)	60W
power consumption (operating with optional unit)	75W
power consumption (standby without optional unit)	10W

Weight and Dimensions

maximum read area	8.5" x 11.7" (216mm x 297mm)
width	13.1" (332mm)
depth	22.1" (562mm)
height	5.2" (133mm)
weight	18.7 lb (8.5 kg approx.)
