Epson Expression 1680 User Manual

92
Network Scanning
Starting EPSON Scan Server
EPSON Scan Server starts automatically whenever the scanner server is turned on.
When EPSON Scan Server is running, you’ll see either the EPSON Scan Server
dialog box, or the EPSON Scan Server icon on the Windows taskbar. If you need
to start EPSON Scan Server manually, click
Start
,
Programs
,
EPSON Scan
Server
, and then select
EPSON Scan Server
.
You can quit EPSON Scan Server at any time. Just click the
Exit
button on the
EPSON Scan Server dialog box.
Before you quit, make sure no client computers are trying to use the
scanner. Don’t exit if the status area of the EPSON Scan Server dialog box
indicates that you are connecting to a client. Wait until you see the
message Waiting for connection.
If you installed EPSON TWAIN Pro on the scanner server so that you could
make a direct connection to the scanner, remember that you must exit
EPSON Scan Server to use EPSON TWAIN Pro. EPSON Scan Server
disables EPSON TWAIN Pro.
Click to exit.
Wait for this message
before you exit.
1680.book Page 92 Thursday, March 1, 2001 4:28 PM

Epson Expression 1680 Specifications

Scanning Specifications

optical resolution	1600 x 3200 dpi
maximum resolution	13, 600 x 18, 720 dpi with interpolation
effective pixels	13, 600 x 18, 720 pixels (1600 dpi)
color depth	48 bits per pixel internal/external
grayscale depth	16 bits per pixel internal/external
scanning speed (color, 1600 dpi, draft mode)	9.2 msec/line (approx.)
scanning speed (grayscale/monochrome, 1600 dpi, draft mode)	3.1 msec/line (approx.)

Operating Environment

temperature operating range	41ºF to 95ºF (5ºC to 35ºC)
humidity operating range	10% to 80% (no condensation)
humidity storage range	10% to 85% (no condensation)

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption (operating without optional unit)	60W
power consumption (operating with optional unit)	75W
power consumption (standby without optional unit)	10W

Weight and Dimensions

maximum read area	8.5" x 11.7" (216mm x 297mm)
width	13.1" (332mm)
depth	22.1" (562mm)
height	5.2" (133mm)
weight	18.7 lb (8.5 kg approx.)
