Epson PLQ-30

❏ Do not use a passbook that has any pages smaller than the cover page.
❏ Do not print on the front or back cover of a passbook. Printing can be done only when the passbook is
opened.
❏ When you use paper that is shorter than 110.0 mm, set the paper eject direction to front. The factory
set default is front. Please access http://www.epson.com for information.
❏ Do not load paper that is curled, folded, or crumpled.
❏ Do not punch holes in the area from 25.0 to 40.0 mm from the left edge of paper. See the illustration
below.
A 25.0 mm
B 15.0 mm
C Do not punch holes in this area.
❏ When using the printer driver, the minimum achievable top and bottom margins are 1.0 mm (0.04
inch) and 9.0 mm (0.36 inch) respectively.
Passbook
Horizontal-fold Vertical-fold
Minimum Maximum Minimum Maximum
Width (mm)
(inch)
110
4.33
241.3
9.5
110
4.33
241.3
9.5
PLQ-30/PLQ-30M User’s Guide
Product Information 112
