Epson PLQ-30 User Manual

3. Turn off the printer.
Unprinted data remaining in the printer is erased.
Uninstalling the Printer Software
When you wish to reinstall or upgrade the printer driver, uninstall the printer driver that has been
installed already.
Note:
When uninstalling EPSON Status Monitor 3 from a multi-user Windows XP or 2000 environment,
remove the shortcut icon from all clients before uninstalling. You can remove the icon by clearing the
Shortcut Icon check box in the Monitoring Preferences dialog box.
Uninstalling the printer driver and EPSON Status Monitor 3
1. Quit all applications.
2. For Windows 8:
Click Desktop on the Start screen, move the cursor to the top-right corner of the screen, click
Settings, and then click Control Panel.
For Windows 7, Vista, or XP:
Click Start, and then select Control Panel.
For Windows 2000:
Click Start, point to Settings, and click Control Panel.
3. Click Uninstall a program (Windows 8, 7, or Vista) or double-click the Add or Remove
Programs icon (Windows XP or 2000).
PLQ-30/PLQ-30M User’s Guide
Printer Software 47

Epson PLQ-30 Specifications

General

Color	-
Bitmap fonts	Courier, Draft, OCR-B, Orator, Prestige, Roman, Sans Serif, Script
Character sets	ISO 8859-15, PC437, PC850, PC858
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, UPC-A, UPC-E
Maximum number of copies	7 copies
Maximum print speed (LQ)	195 cps
Maximum print speed (draft)	360 cps
Maximum printing width (columns)	94
Print direction	Bi-directional
Ribbon life (black, LQ)	5 million characters
Ribbon life (black, draft)	10 million characters
Mean time between failures (MTBF)	12000 h
Standard interfaces	Parallel, RS-232, USB 2.0
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	4.5 W
Power consumption (typical)	64 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows ME, Windows Vista, Windows XP
Product color	Gray
Country of origin	Indonesia
Page description languages	Epson ESC/P2, PPDS
Sound pressure level (printing)	55 dB
Needles	24
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	3710 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	32 pc(s)
Quantity per pallet (UK)	48 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)
Package depth	447 mm
Package width	255 mm
Package height	367 mm
Package weight	9.72 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	280 mm
Width	384 mm
Height	203 mm
