Chapter 6
Options and Consumables
Installing and Using Options
Roll paper holder
The optional roll paper holder (C81114P) allows you to use 8.5-inch roll paper like that used with telex
machines. This provides an alternative for applications requiring variable paper lengths. Before you
install and use the roll paper holder, you need to assemble it.
Assembling the roll paper holder
Follow these steps to assemble the roll paper holder:
1. Fit the arc bearings into the stand as shown.
2. Place the base plate on the stand and fasten the two together with the plastic spacing clips. Make
sure you orient the stand and base plate as shown below.
PLQ-30/PLQ-30M User’s Guide
Options and Consumables 92
