Displacement Standard,
Standard + 10 mm,
Standard + 20 mm
Number of retries 1 or 3
Field duplication YES or NO
Recordable area
Back Cover:
*
H
G
F
I
J
**
*: Magnetic stripe area
**: Recordable area
F (max) G H (min) I J (max)
DIN/ISO, ANSI
12.5 13.9 15.5 9.5 85
IBM3604
8.9 10.4 11.9 10.4 81.3
ISO7811
8.9 10.4 11.9 14.8 —
IBM4746
8.9 10.4 11.9 9.8 —
ISO8484
12.5 13.9 15.3 9.5 85
HT-2751-CIZ
7.4 8.8 10.2 12.6 —
