Appendix D IBM ProPrinter Quick Refernce
D-12
Table 6 (Cont.)
: Graphics Modes
Escape Sequence Mnemonic Function
ESC [ g P1 P2 P3 v1 . . . vn Select Various Graphics Modes (IBM)
P1 + P2 * 256 = number of data
bytes + 1 (P1,P2 = 0/0...F/F)
v1 .. vn = binary data in hex code
Parameter Table Graphic Density:
P3 Graphic type dots max. hor. vert. vert.
per of density density density
column columns ( dpi ) no AGM AGM
0/0 Standard Density (K) 8 816 60 72 60
0/1 Double Density (L) 8 1632 120 72 60
0/2 2xDensity / 2xSpeed (Y) 8 1632 120 72 60 *)
0/3 Quadruple Density (Z) 8 3264 240 72 60 *)
0/8 Standard Density 24 816 60 180 180
0/9 Double Density 24 1632 120 180 180
0/B Triple Density 24 2448 180 180 180
0/C Hex Density 24 4896 360 180 180 *)
*) consecutive horizontal dots cannot be printed.
Example:
box 8x8 dots with center point 2x2 dots, standard density,
8 dots / column
hex: 1B 5B 67 09 00 00 FF 81 81 99 99 81 81 FF
