Table 7: Further Control Sequences, supported by
IBM Emulation Mode
(Native Commands)
Escape Sequence Mnemonic Function
ESC [ $$ Control String Introducer (CSI) for 'ESC ['
ESC $$/ Control String Introducer (CSI) for 'ESC'
ESC * P1 P2 P3 v1 . . . vn Select Various Graphics Modes
P2 + P3 * 256 = number of columns
(P2,P3 = 0/0...F/F)
v1 .. vn = binary data in hex code
Parameter Table Graphic Density:
P1 Graphic type
dots max. hor. vert. vert.
per of density density density
column columns ( dpi ) no AGM AGM
0/0 Standard Density (K) 8 816 60 72 60
0/1 Double Density (L) 8 1632 120 72 60
0/2 2xDensity / 2xSpeed (Y) 8 1632 120 72 60 *)
0/3 Quadruple Density (Z) 8 3264 240 72 60 *)
0/4 CRT I 8 1088 80 72 60
0/5 Plotter 8 979 72 72
0/6 CRT II 8 1224 90 72 60
0/B Double Density Plotter 8 1958 144 72 *)
2/0 Standard Density 24 816 60 180 180
2/1 Double Density 24 1632 120 180 180
2/6 CRT III 24 1224 90 180 180
2/7 Triple Density 24 2448 180 180 180
2/8 Hex Density 24 4896 360 180 180 *)
*) consecutive horizontal dots cannot be printed.
Example:
box 8x8 dots with center point 2x2 dots, standard density,
8 dots / column
hex: 1B 2A 00 08 00 FF 81 81 99 99 81 81 FF
