Epson TM-T88VII User Manual

106
Chapter 6 Replacement of the TM-T88VI/TM-T88V
Additional Functions and Functional Improvements
Print Speed
The default printing speed for the TM-T88VII may vary depending on the specification.
* The values are those when the paper width is set to 80 mm. When it is set to 58 mm, the maximum is
450 mm/s {17.7"/s}.
Interface
In addition to UIB, the printer is equipped with a standard USB interface and a wired LAN interface. You can
perform printing using numerous interfaces.
SimpleAP Function
The TM-T88VII comes with a mode (SimpleAP) that allows the printer to connect directly when using an
optional wireless LAN unit without having to use a wireless LAN access point.
Noise
LED Indicator
The TM-T88VII is equipped with a Wi-Fi LED and an Ethernet LED. Each LED turns on or flashes to indicate
Wi-Fi or Ethernet connection status respectively.
TM-T88VII TM-T88VI TM-T88V
Default
400 ~ 450 mm/s 200 ~ 350 mm/s 300 mm/s
Maximum print speed
500 mm/s 350 mm/s 300 mm/s
Print speed setting
(Customized value)
Level 1 to 17 Level 1 to 14 Level 1 to 13
Depending on print conditions such as print duty, print head temperature, and data transmission
speed, print speed is automatically adjusted.
TM-T88VII TM-T88VI TM-T88V
52 dB 55 dB 55 dB

Epson TM-T88VII Specifications

General

Product color	Black
Type	POS printer
Character sets	ANK
Character size	1.41 x 3.39 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
USB port	Yes
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
Connectivity technology	Wired & Wireless
Wi-Fi	-
Media thickness	48 - 80 mm
Maximum roll diameter	83 mm
Supported paper width	80 mm
AC input voltage	24 V
Power consumption	28600 mA
Power consumption (standby)	1.4 W
Power consumption (printing)	28.6 W
Certification	CE
Internal memory	- MB
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	3 million cuts
Built-in sensors details	Paper End Sensor, Paper Near End Sensor, Cover Open Sensor, Receipt paper sensor
Sound pressure level (printing)	52 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Mean cycles between failures (MCBF)	70000000
Package depth	235 mm
Package height	260 mm
Package weight	2704 g
Quantity per pack	1 pc(s)
Pre-installed software	Server Direct Print, ePOS-Device, ePOS-Display, ePOS-Print
Pallet weight	0 g
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
