Epson TM-T88VII User Manual

114
Appendix
Electrical Characteristics
Supply voltage DC 24V ± 7%
Current consumption
(at 24V, 25°C, normal
print density)
Standby Approx. 0.1 A on average
Up to 1 A for drawer kick driving
Operating Mean: Approximately 1.8A
Note: When print ratio is approximately 18%
• Continuous printing for 30 lines (repeating 20H-7FH)
∗ Font A
∗ 42 columns
∗ ASCII character
• 5 line feeding
• Autocutting

Epson TM-T88VII Specifications

General

Product color	Black
Type	POS printer
Character sets	ANK
Character size	1.41 x 3.39 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
USB port	Yes
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
Connectivity technology	Wired & Wireless
Wi-Fi	-
Media thickness	48 - 80 mm
Maximum roll diameter	83 mm
Supported paper width	80 mm
AC input voltage	24 V
Power consumption	28600 mA
Power consumption (standby)	1.4 W
Power consumption (printing)	28.6 W
Certification	CE
Internal memory	- MB
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	3 million cuts
Built-in sensors details	Paper End Sensor, Paper Near End Sensor, Cover Open Sensor, Receipt paper sensor
Sound pressure level (printing)	52 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Mean cycles between failures (MCBF)	70000000
Package depth	235 mm
Package height	260 mm
Package weight	2704 g
Quantity per pack	1 pc(s)
Pre-installed software	Server Direct Print, ePOS-Device, ePOS-Display, ePOS-Print
Pallet weight	0 g
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
