Chapter 1 Product Overview
Functions
• NFC tag built into the printer unit for printing to a touched printer.
• Printing triggered by bar code scan by smart device camera.
• Supports printing using multiple interfaces.
• Enables HTTPS communication.
• Offers network connection check function.
Others
• Various interface models are available.
• Optional Wireless LAN cable set, customer display, external buzzer, and interface boards are available.
• Optional wall hanging bracket is available to attach the printer to a wall.

Epson TM-T88VII Specifications

General

Product color	Black
Type	POS printer
Character sets	ANK
Character size	1.41 x 3.39 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
USB port	Yes
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
Connectivity technology	Wired & Wireless
Wi-Fi	-
Media thickness	48 - 80 mm
Maximum roll diameter	83 mm
Supported paper width	80 mm
AC input voltage	24 V
Power consumption	28600 mA
Power consumption (standby)	1.4 W
Power consumption (printing)	28.6 W
Certification	CE
Internal memory	- MB
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	3 million cuts
Built-in sensors details	Paper End Sensor, Paper Near End Sensor, Cover Open Sensor, Receipt paper sensor
Sound pressure level (printing)	52 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Mean cycles between failures (MCBF)	70000000
Package depth	235 mm
Package height	260 mm
Package weight	2704 g
Quantity per pack	1 pc(s)
Pre-installed software	Server Direct Print, ePOS-Device, ePOS-Display, ePOS-Print
Pallet weight	0 g
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
