6-2 Notices for Replacement of the TM-U210/TM-U300 Rev. E
6.1.1.2 Characters
TM-U220 has almost the same character spec as the TM-U210. Therefore, the TM-U220 can print
the same contents as the TM-U210 without adjusting any original control sources.
Note:
The character per line for Font A, B can be changed by DIP SW2-1.
The cpl for the Kanji character font can be changed by anESC/POS command. (default:22cpl to 25cpl)
6.1.1.3 Cutting position from print start position
TM-U220 has same distance between the auto cut position and the print start position as the
TM-U210. Therefore the top margin is the same as the previous one when you replace the
TM-U210 with the TM-U220 with autocutter. In other cases, please refer the table and figures
below.
Character spec TM-U210 (Type A,B,D) TM-U220 (Type A,B, D)
Character
par line
(CPI)
Font A (9 x 9) 33 (35) cpl 33 (35) cpl
Font B (7 x 9) 40 (42) cpl 40 (42) cpl
Kanji (16 x 16) 25 (22) cpl 25 (22) cpl
Character
width
Font A (9 x 9) 1.6 x 3.1 1.6 x 3.1
Font B (7 x 9) 1.2 x 3.1 1.2 x 3.1
Kanji (16 x 16) 2.7 x 2.7 2.7 x 2.7
Character configuration Code page 0 to 8, and
19 to 26
Code page 0 to 8, and 19 to
26 and code page 16, 17, 18
Cutting position TM-U210 (Type A,B,D) TM-U220 (Type A,B, D)
Autocutting position to print start
position
27mm 27mm
Manual cut position to print start
position
20.2mm Type D: 22.1mm
TypeA,B: 34.9mm
Cutting method of partial cut one point left uncut position at
center position.
(Type A, B only)
one point left uncut position at
right position.
(Type A, B only)
