Epson TM
U220 Reference Guide

1-4 General Information Rev. E
1.3 Consumables
1.3.1 Ribbons
This printer needs a ribbon cassette to print receipts. We provide 3 ribbon cassettes:
❏ EPSON ribbon cassette, ERC-38 (B) (Life: 3,000,000 characters / Color: Black)
❏ EPSON ribbon cassette, ERC-38 (P) (Life: 4,000,000 characters / Color: Purple)
❏ EPSON ribbon cassette, ERC-38 (B/R) (Life: 1,500,000 characters / Color: Black)
(Life: 750,000 characters / Color: Red)
Note:
These ribbon cassette life numbers are under the EPSON test conditions.
1.3.2 Roll paper
We provide roll paper and carbon roll paper with 1 copy for this printer. The widths are 76 mm,
69.5 mm, and 57.5 mm {3.00"/2.74"/2.26"}.

Epson TM
U220 Specifications

General

Print speed	4.7 lps
Character size	1.6 x 3.1 mm
Print technology	Dot matrix
Paper dimensions	57.5±0.5/69.5±0.5/76±0.5 x 83.0
Dimensions (WxDxH)	160 x 286 x 157.5 mm
Certification	WEEE/RoHS
Mean time between failures (MTBF)	180000 h
Parallel connector	Yes
Standard interfaces	Parallel
